Threshold Conway Cast - Assembly Step 7; Install Middle Shelf

step 7.
Attach the middle shelf (E) to the middle rails of the frames (A, B and C).
NOTE: DO NOT fully tighten all bolts
until you finish assembling all parts.
Once assembled, go back and fully
tighten all bolts. This will make the
assembly easier.
13
(H4) x 4
1/4” x 5/8” bolt
(H5) x 2
1/4” x 1” bolt
H5
E
A
B
C
H4
H4
H4
H4
H5
H5
E
A
B
C
B
E
E
A
C
