step 12: Attach tipping restraint hardware
(H20) x 2
tipping restraint hardware kit
(inside plastic bag)
19
Tools required: Phillips screwdriver, stud finder, tape measure, pencil, power drill and 1/8” drill bit.
12.1. Adjust the pre-attached floor levelers to level the unit against a wall.
12.2. Follow the instructions printed on plastic bag containing tipping restraint hardware to attach tip-over restraint between the unit and the wall.
NOTE: Share the back panel screw hole for the anti-tipping hardware. You must use this tipping restraint to attach this unit to the wall, to prevent accidents
and / or injures.
Floor leveler
Metal bracket
Long screw
Short screw
Wall
Wall
Wooden stud
To Next Page
