Threshold TG3930UC-LS - Step 2: Secure Arms

step 2.
(H1) x 2 (H5) x 2
hex socket head bolt spring washer
1.77" ø12.5mm
(H3) x 2 (H6) x 1
flat washer allen key
ø22mm M5
7
1. Attach left arm (A) and right arm (B) to chair back (C)
with hex socket head bolts (H1), flat washers (H3) and
spring washers (H5).
2. Use Allen Key (H6) to tighten the hex socket head bolts (H1).
H3
H5
H1
H6
B
C
A
