Attaching the racing wheel to a racing cockpit (not included)
1. Place the base of the racing wheel on the cockpit’s shelf.
2. Screw two M6 screws (not included) into the cockpit’s shelf and into the two threaded holes on the
underside of the racing wheel (19).
Important
The length of the two M6 screws must not exceed the thickness of the shelf by more than 0.47
inches/12 mm; longer screws could cause damage to internal components located in the racing
wheel’s base.
3. If necessary, you can also screw the standard attachment system (13, 14) into the large threaded
hole (18).
The T248 racing wheel’s setup diagrams for cockpits and other supports are available at
https://support.thrustmaster.com: click Racing Wheels / T248, and then Template - Cockpit
Setup.
