7/18
INSTALLING THE RACING WHEEL ON ITS BASE
Align the connector positions using the arrows:
Base (1) connector: Arrow pointing upwards
Racing wheel (2) connector: Arrow pointing upwards
Once the connectors are correctly positioned, simply rotate the Thrustmaster Quick Release (12) device’s
ring counterclockwise, while holding the racing wheel (2) in position.
Then, tighten the ring as much as you can: to do so, hold the ring in position and rotate the racing wheel
clockwise.
Once you have installed the racing wheel, rotate it 180° (when facing the wheel, the PlayStation® logo
should be upside down) to access the small attachment screw located on the ring of the Thrustmaster
Quick Release (12) device. Use a large Phillips screwdriver to tighten the small attachment screw (do not
use excessive force), turning it clockwise.
Do not use excessive force when tightening the small attachment screw
(using a Phillips screwdriver)!
Stop turning the screw as soon as you feel some resistance.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Thrustmaster T300RS and is the answer not in the manual?

Thrustmaster T300RS Specifications

General IconGeneral
TypeRacing Wheel
Force FeedbackYes
CompatibilityPC, PlayStation 3, PlayStation 4
ConnectivityUSB
Power SupplyExternal power adapter
Pedals IncludedYes
Rotation Angle270° to 1080°
Wheel Diameter28 cm / 11 inches
MountingClamp or screw
Dimensions32 x 27 x 26 cm
Buttons13 (including 2 on the base) + 1 D-Pad
