Thrustmaster TCA QUADRANT AIRBUS EDITION User Manual

7/18
DISABLING THE THRUST REVERSERS ON THE TCA
QUADRANT AIRBUS EDITION THROTTLE QUADRANT
The TCA Quadrant Airbus Edition throttle quadrant features functional thrust revers ers,
replicating those found on Airbus commercial aviation throttles. You can disable the thrust
reverser mechanism, for piloting better suited to civil aviation.
Commercial airliner mode:
1. At the stop, lift up the thrust reverser mechanism.
2. Moving past the stop lets you use the thrust reverser.
General and civil aviation mode:
1. Lift up the thrust reverser mechanism.
2. Turn the selector to position 0 to disable the thrust reverser mechanism.
3. The thrust lever can now move through the entire axis.
2
1
2
1
3

Thrustmaster TCA QUADRANT AIRBUS EDITION Specifications

General

Type	Throttle Quadrant
Connectivity	USB
Weight	1.5 kg
Axis	3
Throttle Levers	2
Adjustable Resistance	Yes
Manufacturer	Thrustmaster
Compatibility	PC
Features	Detachable Throttle Levers
