Thuasne Sleeq Flex - Brace Use and Reset; Donning and Doffing Instructions; Removing the Brace; Resetting the Tightening Mechanism

Pull downward on straps to
tighten shoulder harness.
c
c
1
2
L
R
Detach pull tabs and adjust
compression by pulling forward
and re-attaching the pull tabs
to the front of the brace.
Removing Brace:
Loosen shoulder straps, detach pull tabs from front of brace and re-attach laterally. Separate wings and
slide brace o over the shoulders. Reset brace.
3
3.0 Reset
When removing the brace, always replace Pull Tabs D to ready position (3.1). Lay brace on a flat surface then pull both
Wings J outward to reset the tightening mechanism (3.2).
3.1 3.2
2.3 2.4
2.5 2.72.6
2.0 Donning/Dong
First loosen the shoulder straps,
don brace over the shoulders.
Adjust “ThoraCare” strap up or down to
accommodate larger patients. Position brace
to desired height (T-3 / scapular spine level).
(1) Wrap left wing to align with
medial line of abdomen.
(2) Wrap right wing and attach
at mid-line.
