i
-
T
o ins
tall locks (available
separ
a
tely), remove the knob
plug by turning 90 degrees
clockwise. Install locks as shown
using change key, lock cylinders
and locking keys included with
the lock set.
A B C D
SW
EDEN
E
SW
EDEN
180°
5067058_01
- FOR
AEROBLADE:
A. Cut under bar co
ver strips to fit between outside of foot and
inside of endcap. S
trips should cover endcap retention tab. Press
carefully into place.
- B. Slide tab on SmartSlides up against f
eet.
6
A
B
