Thule 450R - Step 2: Adapter Installation (Ford Explorer)

5015527_05
2
20
11- FORD EXPLORER OWNERS ONLY
- A. Insert adapt
er (B) into rail so that part number faces in and ‘wings’
f
ace up.
20
11- FORD EXPLORER OWNERS ONLY
- B. R
otate adapter down towards roof. Adapter may click into place.
20
11- FORD EXPLORER OWNERS ONLY
- C. A
dapter can slide side-to-side in rail to match desired foot position.
B
A
C
