3.6 InStallInG the front Wheel
A. Unfoldthefender,byliftingitupandslidingittothe
sideuntilitsnapsinplace.(Seeimage1)
B. Installquick-releaseskewerintothefrontwheel:
(Seeimage2)
i. Unscrewandremovethequick-releaseknob.
ii. Removeoneofthesprings.
iii. Insertthequick-releaseskewerthroughthe
joggingwheel.
iv. Replacethespringbackontothequick-release
skewer,narrowendpointinginward,towardthe
frontwheel.
v. Replaceandtightenthequick-releaseknob.
C. Installthefrontwheelintothewheeldropouts.
(Seeimage3)
i. Tightenthequick-releaseknobuntilngertight.
D. Attachthefrontbrakebyconnectingthebrakecableto
bothbrakearms.(Seeimage4)
3
4
1
2
WARNING
Always make sure that the skewer is correctly
installed. An incorrectly tensioned quick-release
skewer may lead to loss of the front wheel.
