5
Specifications
SPECIFICATIONS
MODEL TDR15005 TDR15006 TDR15007
TYPE Monocrystalline Monocrystalline Monocrystalline
MAX POWER 80W (2x40W) 160W (2x80W) 240W(3x80W)
OPEN CIRCUIT VOLTAGE 23.9V 22.5V 22.5V
SHORT CIRCUIT CURRENT 4.39A 9.46A 14.2A
MAX POWER VOLTAGE 20V 18V 18V
MAX POWER CURRENT 4A 8.89A 13.3A
DIMENSIONS (CLOSED) 675mm(L) x 460mm(W) x 70mm(D) 780mm(L) x 675mm(W) x 70mm(D) 780mm(L) x 675mm(W) x 105mm(D)
DIMENSIONS (OPEN) 1350mm(L) x 460mm(W) x 35mm(D) 1350mm(L) x 780mm(W) x 35mm(D) 2340mm(L) x 675mm(W) x 35mm(D)
OPERATING TEMP -40° to 85°C -40° to 85°C -40° to 85°C
WEIGHT 8.2Kg 18.5Kg 20.5Kg
SOLAR PANEL REGULATOR
TYPE PWM
RATED VOLTAGE 12VDC/24VDC
RATED CURRENT 7A-20A
MAX INPUT VOLTAGE 25V
OPERATING VOLTAGE 8V (Regulator will not recognise a battery lower than 8V)
OPERATING TEMPERATURE -20°C to 60°C
RECOMMENDED BATTERIES (NOT INCLUDED)
TYPE 12V (60Ah - 100Ah Lead Acid or GEL type)
