ThyssenKrupp Flow2 User Manual

2007.03.07 Flow2 stairlift Tab 06: Systematic fault finding
www.ThyssenKruppAccessibility.nl 27
Error messages
Possible
solution
- Switch to mode 3 and press the [E] button. Levelling must now move to
the 0 position.
If the levelling of the chair works correctly, this error can have occurred
because the lift went around a corner too quickly so that the level motor
was unable to keep the chair horizontal. It is also possible that the level
motor had insufficient force in this situation.
If the nulling of the chair does not work in mode 3, there is a hardware
fault.
- Check the connections on the sensor board.
- Check the cable between the sensor board and the main board.
- Check the connections on the motor module of the level motor.
- Replace the sensor board if it behaves suspiciously.
- Replace the motor module of the level motor if it behaves suspiciously.
- Replace the main board if none of the above solutions has helped or if the
fault keeps coming back. This is an extreme measure.
Reset Switch off and on
Modes 0, 1, 2
Error code E53
Type of error User error / system error
Error message Left-handed squeeze condition
Description The lift has been stopped by an obstacle on the left side of the chair.
Priority Low
Possible
solution
- If possible, allow the lift to move to the right and remove the obstacle.
If error code E54 appears, switch the lift to mode 3 and use the [I] and [D]
buttons to 'release' the lift from the squeeze condition.
- If the error occurs without there being a squeeze condition, check the
squeeze opto and the connection cable.
Replace defective parts.
Reset Stop the lift
Modes 0, 2
