3.3.2.2 Full enroute swivel seat
The stairlift is equipped with the patented ASL (Advanced Swivel and
Leveling) technology that makes the chair rotate and stay level. The
technology offers the user maximum comfort. The swivel points of the
chair are individually programmed in such a way that the user is always in
the best possible seating position. The simultaneous movement of the
swivel and leveling module keeps the chair in a horizontal position, independent of the
angle the rail is inclining or declining.
Additional stops and swivel moments during the ride are avoided. The chair rotation at
the bottom or top of the staircase makes it easier to get on and off the stairlift. With the
ASL technology, the stairlift can be installed in small and narrow staircases while making
sure that other persons can still walk the stairs. Remodeling work at the staircase is not
necessary.
Before you sit down or stand up, the chair will automatically turn into the required
direction when you control the stairlift with the joystick user interface or the call-and-park
station. The chair can also turn backwards when you go upstairs and forward when you
go downstairs.
Instructions
Sitting down
1. Push the call button on the call-and-park control station to call the chair to the
Halt position and turn the chair into the boarding position.
2. Turn both armrests to the open position (position 3, see 4.1.1) until you hear and
feel that the armrests are locked.
3. Unfold the seat.
5. Sit down on the chair.
6. Unfold the footrest.
7. Put the armrests in position 2 (45 degrees inwards (depending on configuration)
see 4.1.1).
8. Fasten the safety belt.
9. Pull the joystick in upright position, then push and hold it to the left or to the
right to move the stairlift. The chair will turn into the riding position and start
moving.
12 Description
