Arriving at the top or the bottom of the stairs
1. Push and hold the joystick to the left or to the right until you have arrived at the
top or the bottom of the stairs. The chair will stop driving and turn automatically.
2. When you hear an audio signal, release the joystick and fold it down.
3. Release the safety belt.
4. Put the armrests in position 3 (straight forward) see 4.1.1).
5. Fold the footrest.
6. Stand up from the seat.
7. Fold the seat.
The footrest will automatically fold up as well.
8. Put the armrests in position 1 (closed).
9. Push the park button on the call-and-park control station to park the stairlift at a
parking point.
3.3.3 Automatic seat folding
By pressing the corresponding button on the
armrest for more than 1 second, the seat can be
folded in or out automatically.
26. Options user interface
27. Automatic seat folding button
Press the button for more than 1 sec.
to fold or unfold the seat.
CAUTION
Ensure that the armrest is locked in
position 3 (see 4.1.1) and ensure that
the safety belt is disengaged (see
4.1.1)
27
26
Description 13
