Thytronic NVA100X User Manual

21
NVA100X - Getting started - 01 - 2018
SET
NVA100X_menuset1.ai
PROCEED SET MENU’
BASE >>
PROCEED PROFILE A MENU’
(U/f)> Enable OFF
Type Characteristic
(U/f)>Curve
DEFINITE
t(U/f)>RES 0.1 s
(U/f)>def OFF
1 Un/fn
t(U/f)>def 1 s
(U/f)>inv OFF
1 Un/fn
t(U/f)>inv 5 s
(U/f)>BLK1 OFF
(U/f)>BF OFF
(U/f)AL...
disby(U/f)> OFF
Relays (U/f)>
(U/f)>ST-K -
(U/f)>TR-K -
LEDs (U/f)>
(U/f)>ST-L -
(U/f)>TR-L -
(U/f)>> Enable OFF
(U/f)>>def OFF
1 Un/fn
t(U/f)>>def 1 s
t(U/f)>inv 5 s
(U/f)>>BLK1 OFF
(U/f)>>BF OFF
(U/f)AL...
disby(U/f)>> OFF
(U/f)>...
disby(U/f)>> OFF
Relays (U/f)>>
(U/f)>>ST-K -
(U/f)>>TR-K -
LEDs (U/f)>>
(U/f)>>ST-L -
(U/f)>>TR-L -
Plant
..................
Reading RELATIVE
IE Selected IE
Measure UE or UL4
UE
Phase correction
UL1-UL4 0 deg
In 5 A
Inp 100 A
IEn 1 A
IEnp 100 A
Un 100 V
Unp 20000 V
UEn 100 V
UEnp 20000 V
fn 50 Hz
LANGUAGE English
AUTO-RECLOSE 79 >>
79 Enable OFF
79 Mode Rapid+Slow
N.DAR 3
trdt 0.3 s
tsdt 30 s
tr 180 s
td1 5 s
td2 5 s
MC-td-EN OFF
td 5 s
MO-RES ON
Phase trip
79-I> OFF
79-I>> OFF
79-I>>> OFF
79-IPD> OFF
79-IPD>> OFF
79-IPD>>> OFF
79-IPD>>>> OFF
Earth trip
79-IE> OFF
79-IE>> OFF
79-IE>>> OFF
79-IED> OFF
79-IED>> OFF
79-IED>>> OFF
79-IED>>>> OFF
External trip
79-Ext OFF
Relays 79
79-Run-K -
79-AR-K -
79-Fail-K -
79-EnableState-K -
LEDs 79
79-Run-L -
79-AR-L -
79-Fail-L -
79-EnableState-L -
INPUT SEQUENCE >>
I-Sequence
IL1-IL2-IL3 Def.
V-Sequence
UL1-UL2-UL3 Def.
SELF-TEST RELAY >>
Minor failure
alarm NO
Self-test relay -
PROFILE A
>>
PROFILE
SELECTION >>
Active Profile A
MMI >>
Param. setting
enable ON
Modules data
visualization
ASSIGNED MODULES
POLARITY >>
A1-A2 NORMAL
A3-A4 NORMAL
A5-A6 NORMAL
A7-A8 NORMAL
B3-B4 NORMAL
B5-B6 NORMAL
B7-B8 NORMAL
B9-B10 NORMAL
LINE >>
R1L 0.05 mZNf/km
X1L 0.05 mZNf/km
R0L 0.05 mZNf/km
X0L 0.05 mZNf/km
L 10 km
Logic Active-ON
ON Delay
IN1-1 tON 0 s
OFF Delay
IN1-1 tOFF 0 s
IN1-1 matching None
Logic Active-ON
ON Delay
IN1-x tON 0 s
OFF Delay
IN1-x tOFF 0 s
IN1-2 matching None
Logic Active-ON
ON Delay
IN1-2 tON 0 s
OFF Delay
IN1-2 tOFF 0 s
IN1-2 matching None
ENABLE
VECTOR JUMP >>
Endphi ON
0.2 En
tEndphi 0.5 s
INPUTS
IN1-1...IN1-16 >>
Binary input IN1-1
Setpoints >>
Binary input IN1-2
Setpoints >>
Binary input IN1-x
Setpoints >>
Logic ENERGIZED
OPERATION MODE
LATCHED
Minimum pulse width
KC1-1 tTR 150 ms
Logic ENERGIZED
OPERATION MODE
LATCHED
Minimum pulse width
KC1-2 tTR 150 ms
Logic ENERGIZED
OPERATION MODE
LATCHED
Minimum pulse width
KCx-x tTR 150 ms
RELAYS
KC1-1...KC1-8 >>
IB >>
IB 1 In
24 >>
(U/f)> Element >>
(U/f)AL Element >>
(U/f)>> Element >>
(U/f)AL Enable OFF
(U/f)ALdef OFF
1 Un/fn
t(U/f)ALdef 1 s
(U/f)ALBLK1 OFF
Relays(U/f)AL
(U/f)ALST-K -
(U/f)ALTR-K -
LEDs(U/f)AL
(U/f)ALST-L -
(U/f)ALTR-L -
25 >>
Common >>
25 Enable OFF
25 Logic
0-V1 and V4 Live
tSTAB 0.1 s
tCB_CLOSE 0.02 s
timeout-SYNC 10 min
tSYNC 0.1 s
Vmax-SYNC 0.8 En
Vmin-SYNC 0.3 En
fRANGE 1 Hz
Rof>SYNC 0 Hz
U< Enable OFF
Type Characteristic
U<Curve
DEFINITE
U<def OFF
0.5 Un
tU<def 1 s
U<inv OFF
0.5 Un
tU<inv 10 s
U<BF OFF
Relays U<
U<ST-K -
U<TR-K -
LEDs U<
U<ST-L -
U<TR-L -
Utype27 Uph-ph
Rof>SYNC 0 Hz
U<<def OFF
0.5 Un
tU<<def 1 s
U<<BLK1 OFF
U<disbyU<< OFF
U<<BF OFF
Relays U<<
U<<ST-K -
U<<TR-K -
LEDs U<<
U<<ST-L -
U<<TR-L -
Setpoints >>
27 >>
Common >>
U< Element >>
U<< Element >>
df-NET 0.02 Hz
df14-SYNC 0.05 Hz
df41-SYNC 0.05 Hz
dv14-SYNC 0.05 Un
dv41-SYNC 0.05 Un
dp14-SYNC 3 deg
dp41-SYNC 3 deg
V1>SYNC ON
0.5 En
tV1>SYNC 1 s
V4>SYNC ON
0.5 En
tV4>SYNC 1 s
V1<SYNC ON
0.2 En
tV1<SYNC 1 s
V4<SYNC ON
0.2 Un
tV4<SYNC 1 s
Relays 25
Sync-ST-K -
Sync-TR-K -
LEDs 25
Sync-ST-L -
Sync-TR-L -
KC1-1 relay
Setpoints >>
KC1-2 relay
Setpoints >>
KC1-x relay
Setpoints >>
LEDS
ON MMI >>
Start LED logic
NO LATCHED
Trip LED logic
NO LATCHED
LED 1 logic
NO LATCHED
LED 2 logic
NO LATCHED
LED 3 logic
NO LATCHED
LED 4 logic
NO LATCHED
LED 5 logic
NO LATCHED
LEDS
LED1-1...LED1-8 >>
LED1-1 logic
NO LATCHED
LED1-2 logic
NO LATCHED
LED1-3 logic
NO LATCHED
LED1-4 logic
NO LATCHED
LED1-x logic
NO LATCHED
LED1-8 logic
NO LATCHED
