Thytronic NVA100X User Manual

25
NVA100X - Getting started - 01 - 2018
NVA100X_menuset4.ai
PREVIOUS SET MENU’
PREVIOUS PROFILE A MENU’
PROCEED SET MENU’
SET
PROFILE A
PROCEED PROFILE A MENU’
55 >>
Common >>
CPhi1< DIR
CosPhi Lag
CPhi1<def enable OFF
CPhi1<def 0.90
tCPhi1<def 1.00 s
CPhi1<BLK1 OFF
CPhi1<BF OFF
Relays CPhi1<
CPhi1<ST-K -
CPhi1<TR-K -
LEDs CPhi1<
CPhi1<ST-L -
CPhi1<TR-L -
CPhi2< DIR
CosPhi Lag
CPhi1<def enable OFF
CPhi2<def 0.90
tCPhi2<def 1.00 s
CPhi2<BLK1 OFF
CPhi2<BF OFF
Relays CPhi2<
CPhi2<ST-K -
CPhi2<TR-K -
LEDs CPhi2<
CPhi2<ST-L -
CPhi2<TR-L -
CB-55 Enable OFF
tARM-CPhi< 1.00 s
CPh1< Element >>
CPh2< Element >>
59N >>
Common >>
U> Enable OFF
Type Characteristic
UE>Curve DEFINITE
tUE>RES 0 s
UE>def OFF
0.1 UEn
tUE>def 1 s
UE>inv OFF
0.1 UEn
tUE>inv 10 s
UE>BLK1 OFF
UE>BF OFF
Relays UE>
UE>ST-K -
UE>TR-K -
LEDs UE>
UE>ST-L -
UE>TR-L -
tUE>>RES 0 s
UE>>def OFF
0.1 UEn
tUE>>def 1 s
UE>>BLK1 OFF
U>>BF OFF
UE>disbyUE>> OFF
Relays UE>>
UE>>ST-K -
UE>>TR-K -
LEDs UE>>
UE>>ST-L -
UE>>TR-L -
3VoType59N UE
74VTint59N OFF
74VText59N OFF
Common >>
Mode67 I
Logic67 1/3
74VTint67 OFF
74VText67 OFF
UE> Element >>
U>> Element >>
59V2 >>
U2>def OFF
0.1 En
tU2>def 1 s
U2>BLK1 OFF
U2>BF OFF
Relays U2>
U2>ST-K -
U2>TR-K -
LEDs U2>
U2>ST-L -
U2>TR-L -
U2> Element >>
66 >>
66 Enable OFF
Type66 NST
tC 1 min
NST 10
TST 30 s
TIN 0 min
66BLK1 OFF
Relays 66
66-TR-K -
LEDs 66
66-TR-L -
59 >>
Common >>
U> Enable OFF
Type Characteristic
U>Curve DEFINITE
U>def enable OFF
U>def 1 Un
tU>def 1 s
U>inv enable OFF
U>inv 1 Un
tU>inv 10 s
U>BLK1 OFF
U>BF OFF
Relays U>
U>ST-K -
U>TR-K -
LEDs U>
U>ST-L -
U>TR-L -
U>>def Enable OFF
U>>def 1 Un
tU>>def 1 s
U>>BLK1 OFF
U>disbyU>> OFF
U>>BF OFF
Relays U>>
U>>ST-K -
U>>TR-K -
LEDs U>>
U>>ST-L -
U>>TR-L -
Utype59 Uph-ph
Logic59 OR
U> Element >>
U>> Element >>
67 >>
IPD> Element >>
IPD> Enable OFF
Type
Characteristic:
IPD>Curve DEFINITE
IPDCLP> Mode OFF
tPDCLP> 0.1 s
tPD>RES 0 s
IPD>def OFF
1 In
ThetaP>def 0 gr
IPDCLP>def 1.5 In
tPD>def 1 s
IPD>inv OFF
1 In
ThetaP>inv 0 gr
IPDCLP>inv 1.5 In
tPD>inv 10 s
IPD>BLK1 OFF
IPD>BLK2IN OFF
IPD>BLK2OUT OFF
IPD>BLK4 OFF
IPD>2ndh-REST OFF
IPD>BF OFF
Relays IPD>
IPD>ST-K -
IPD>TR-K -
LEDs IPD>
IPD>ST-L -
IPD>TR-L -
IPD>>> Enable OFF
IPDCLP>>> Mode OFF
tPDCLP>>> 0.1 s
tPD>>>RES 0 s
IPD>>>def OFF
1 In
ThetaP>>>def 0 gr
IPDCLP>>>def 1.5 In
tPD>>>def 1 s
IPD>>>BLK1 OFF
IPD>>>BLK2IN OFF
IPD>>>BLK2OUT OFF
IPD>>>BLK4 OFF
IPD>>>2ndh-REST OFF
IPD>>>BF OFF
IPD>disbyIPD>>> OFF
IPD>>disbyIPD>> OFF
Relays IPD>>>
IPD>>>ST-K -
IPD>>>TR-K -
LEDs IPD>>>
IPD>>>ST-L -
IPD>>>TR-L -
IPD>>>> Enable OFF
ST-IPD>>>>&STU<<
OFF
IPDCLP>>>> Mode OFF
tPDCLP>>>> 0.1 s
tPD>>>>RES 0 s
IPD>>>>def OFF
1 In
ThetaP>>>>def 0 gr
IPDCLP>>>>def 1.5 In
tPD>>>>def 1 s
IPD>>>>BLK1 OFF
IPD>>>>BLK2IN OFF
IPD>>>>BLK2OUT OFF
IPD>>>>BLK4 OFF
IPD>>>>2ndh-REST OFF
IPD>>>>BF OFF
IPD>disbyIPD>>>> OFF
IPD>>disbyIPD>>> OFF
IPD>>>disbyIPD>>>> OFF
Relays IPD>>>>
IPD>>>>ST-K -
IPD>>>>TR-K -
LEDs IPD>>>>
IPD>>>>ST-L -
IPD>>>>TR-L -
IPD>> Enable OFF
Type
Characteristic:
IPD>>Curve DEFINITE
IPDCLP>> Mode OFF
tPDCLP>> 0.1 s
tPD>>RES 0 s
IPD>>def OFF
1 In
ThetaP>>def 0 gr
IPDCLP>>def 1.5 In
tPD>>def 1 s
IPD>>inv OFF
1 In
ThetaP>>inv 0 gr
IPDCLP>>inv 1.5 In
tPD>>inv 5 s
IPD>>BLK1 OFF
IPD>>BLK2IN OFF
IPD>>BLK2OUT OFF
IPD>>BLK4 OFF
IPD>>2ndh-REST OFF
IPD>>BF OFF
IPD>disbyIPD>> OFF
Relays IPD>>
IPD>>ST-K -
IPD>>TR-K -
LEDs IPD>>
IPD>>ST-L -
IPD>>TR-L -
IPD>> Element >>
IPD>>>> Element >>
IPD>>> Element >>
