40
TECHNICAL DATA
0.100...0.999 I
n
(step 0.001 I
n
)
1.00...9.99 I
n
(step 0.01 I
n
)
10.0...40.0 I
n
(step 0.1 I
n
)
Characteristic angle (Theta
PD>>def
) 0...359° (step 1°)
I
PD
>>
def
within CLP (I
PDCLP>>def
) 0.100...40.0 I
n
0.100...0.999 I
n
(step 0.001 I
n
)
1.00...9.99 I
n
(step 0.01 I
n
)
10.0...40.0 I
n
(step 0.1 I
n
)
Operating time (t
PD
>>
def
) 0.05...200 s
0.05...9.99 s (step 0.01 s)
10.0...99.9 s (step 0.1 s)
100...200 s (step 1 s)
Definite time
for ThySensor input versions
Second threshold definite time (I
PD
>>
def
) 0.010...30.0 I
n
0.010...0.999 I
n
(step 0.001 I
n
)
1.00...9.99 I
n
(step 0.01 I
n
)
10.0...30.0 I
n
(step 0.1 I
n
)
Characteristic angle (Theta
PD>>def
) 0...359° (step 1°)
I
PD
>>
def
within CLP (I
PDCLP>>def
) 0.010...30.0 I
n
0.010...0.999 I
n
(step 0.001 I
n
)
1.00...9.99 I
n
(step 0.01 I
n
)
10.0...30.0 I
n
(step 0.1 I
n
)
Operating time (t
PD
>>
def
) 0.05...200 s
0.05...9.99 s (step 0.01 s)
10.0...99.9 s (step 0.1 s)
100...200 s (step 1 s)
Inverse time
Second threshold inverse time (I
PD
>>
inv
) 0.100...10.0 I
n
0.100...0.999 I
n
(step 0.001 I
n
)
1.00...10.00 I
n
(step 0.01 I
n
)
Characteristic angle (Theta
PD>>inv
) 0...359° (step 1°)
I
PD
>>
inv
within CLP (I
PDCLP>>inv
) 0.100...10.0 I
n
0.100...0.999 I
n
(step 0.001 I
n
)
1.00...10.00 I
n
(step 0.01 I
n
)
Operating time (t
PD
>>
inv
) 0.02...60.0 s
0.02...9.99 s (step 0.01 s)
10.0...60.0 s (step 0.1 s)
I
PD
>>> Element
CLP operating mode (I
PDCLP
>>> Mode) OFF/ON-Element blocking/ON-Change setting
CLP activation time (t
PDCLP>>>
) 0.00...100.0 s
0.00...9.99 s (step 0.01 s)
10.0...100.0 s (step 0.1 s)
Reset time delay (t
PD
>>>
RES
) 0.00...100.0 s
0.00...9.99 s (step 0.01 s)
10.0...100.0 s (step 0.1 s)
Definite time for CTs input versions
Third threshold definite time (I
PD
>>>
def
) 0.100...40.0 I
n
0.100...0.999 I
n
(step 0.001 I
n
)
1.00...9.99 I
n
(step 0.01 I
n
)
10.0...40.0 I
n
(step 0.1 I
n
)
Characteristic angle (Theta
PD>>>def
) 0...359° (step 1°)
I
PD
>>>
def
within CLP (I
PDCLP>>>def
) 0.100...40.0 I
n
0.100...0.999 I
n
(step 0.001 I
n
)
1.00...9.99 I
n
(step 0.01 I
n
)
10.0...40.0 I
n
(step 0.1 I
n
)
Operating time (t
PD
>>>
def
) 0.05...10.00 s (step 0.01 s)
Definite time
for ThySensor input versions
Third threshold definite time (I
PD
>>>
def
) 0.010...30.0 I
n
0.010...0.999 I
n
(step 0.001 I
n
)
1.00...9.99 I
n
(step 0.01 I
n
)
10.0...30.0 I
n
(step 0.1 I
n
)
Characteristic angle (Theta
PD>>>def
) 0...359° (step 1°)
I
PD
>>>
def
within CLP (I
PDCLP>>>def
) 0.010...30.0 I
n
0.010...0.999 I
n
(step 0.001 I
n
)
1.00...9.99 I
n
(step 0.01 I
n
)
10.0...30.0 I
n
(step 0.1 I
n
)
Operating time (t
PD
>>>
def
) 0.05...10.00 s (step 0.01 s)
I
PD
>>>> Element
CLP operating mode (I
PDCLP
>>>> Mode) OFF/ON-Element blocking/ON-Change setting
XMR-D EQUIPMENT MANUAL
Ed. 2.9 - 02/2021
