FUNCTION CHARACTERISTICS
ELEMENTS
LEDs
START TRIP 1 2 3 4 ...
..16
24 Alarm element Start LEDs (U/f)AL-ST-L)
24 Alarm element Trip LEDs (U/f)AL-TR-L)
24 First element Start LEDs (U/f)>ST-L)
24 First element Trip LEDs (U/f)>TR-L)
24 Second element Start LEDs (U/f)>>ST-L)
24 Second element Start LEDs (U/f)>>TR-L)
27 First element Start LEDs (U<ST-L)
27 First element Trip LEDs (U<TR-L)
27 Second element Start LEDs (U<<ST-L)
27 Second element Start LEDs (U<<TR-L)
27V1 First element Start LEDs (U1<ST-L)
27V1 First element trip LEDs (U1<TR-L)
32P First element Start LEDs (P1>ST-L)
32P First element Trip LEDs (P1>TR-L)
32P Second element Start LEDs (P2>ST-L)
32P Second element trip LEDs (P2>TR-L)
32Q First element Start LEDs (Q1>ST-L)
32Q First element Trip LEDs (Q1>TR-L)
32Q Second element Start LEDs (Q2>ST-L)
32Q Second element Trip LEDs (Q2>TR-L)
37 First element Start LEDs (I<ST-L)
37 First element Trip LEDs (I<TR-L)
37P First element Start LEDs (P1<ST-L)
37P First element Trip LEDs (P1<TR-L)
37P Second element Start LEDs (P2<ST-L)
37P Second element Trip LEDs (P2<TR-L)
37Q First element Start LEDs (Q1<ST-L)
37Q First element Trip LEDs (Q1<TR-L)
37Q Second element Start LEDs (Q2<ST-L)
37Q Second element trip LEDs (Q2<TR-L)
40AL Alarm element Start LEDs (40ALST-L)
40AL Alarm element Trip LEDs (40ALTR-L)
XC1-XD1 First element Start LEDs (XC1-XD1ST-L)
XC1-XD1 First element Trip LEDs (XC1-XD1TR-L)
XC2-XD2 Second element Start LEDs (XC2-XD2ST-L)
XC2-XD2 Second element Trip LEDs (XC2-XD2TR-L)
46LT First element Start LEDs (I2LT>ST-L)
46LT First element Trip LEDs (I2LT>TR-L)
46LT Second element Start LEDs (I2LT>>ST-L)
46LT Second element Trip LEDs (I2LT>>TR-L)
46M First element Start LEDs (I2M>ST-L)
46M First element Trip LEDs (I2M>TR-L)
46M Second element Start LEDs (I2M>>ST-L)
46M Second element Trip LEDs (I2M>>TR-L)
46G First element Start LEDs (I2GAL>ST-L)
46G First element Trip LEDs (I2GAL>TR-L)
46G Second element Start LEDs (I2G>>ST-L)
46G Second element Trip LEDs (I2G>>TR-L)
I21 First element Start LEDs (I21>ST-L)
I21 First element Trip LEDs (I21>TR-L)
47 First element Trip LEDs (47TR-L)
49LT First alarm element Trip LEDs (DthLTAL1-L)
49LT Second alarm element Trip LEDs (DthLTAL2-L)
49LT First alarm element Trip LEDs (DthLT>-L)
49MG First alarm element Trip LEDs (DthMGAL1-L)
49MG Second alarm element Trip LEDs (DthMGAL2-L)
49MG First alarm element Trip LEDs (DthMG>-L)
50/51 First element Start LEDs (I>ST-L)
50/51 First element Trip LEDs (I>TR-L)
50/51 Second element Start LEDs (I>>ST-L)
50/51 Second element Trip LEDs (I>>TR-L)
50/51 Third element Start LEDs (I>>>ST-L)
50/51 Third element Trip LEDs (I>>>TR-L)
XMR-D EQUIPMENT MANUAL
Ed. 2.9 - 02/2021
