Tie Down Engineering 80 User Manual

2
2X
18
16
17
2X 6
2X
8
3
1
7
6X
14
9
4
13
5
4X
11
15
10
NOITPIRCSEDREBMUN TRAP.YTQ.ON METI
11 70461 COUPLER AND MASTER CYLINDER ASSY.
2170466-12012 MODEL 80 FORMED ACTUATOR HOUSING
3170462-2 2012 MODEL ACTUATOR HOUSING BRIDGE PLATE
4170462-3 2012 FRONT COVER PLATE
5170462-4 2012 REAR COVER PLATE
62 47245ROLLER FOR 17018 6600LB ACTUATOR
TLOB L "4 x FN02-2/16427427
82 10661NUTLOCK REVERSE 1/2-20 ZINC
9170470-4 MOLDED MASTER CYLINDER CAP
10 1 70470-3 MASTER CYLINDER PAPER GASKET
11 1 11286 VALVE SOLENOID 2WNC OPTIONAL BACK FLOW
12 4 10518BOLT HHCS 1/4-20 x 3/4 GR 5 - ZINC
13 6 1054810-32 HEX WASHER HEAD THREAD ROLLING SCREW - ZINC
GNIRPS ELBAC YTEFAS44884141
15 4 105541/4" SPRING LOCK WASHER - ZINC
ELBAC & NIP YTEFAS 10305161
17 1 10503SCREW, 1/4-20 x 1/2" SELF TAP
18 1 5031766, 70 & 80 E-STOP CABLE ASSEMBLY
4x - 12
Model 80/800* Actuator
8,000 lbs Capacity
Disc Brake Part Detail
*Model 800 - Manufactured
after March 2012

Tie Down Engineering 80 Specifications

General

Brand	Tie Down Engineering
Model	80
Category	Controller
Language	English
