Instruction #08348 (E1834 Rev. 3/29/21)
Safety Products Division
605 Stonehill Drive SW
Atlanta, Georgia 30336
800-241-1806 • 404-344-0000
Page 4 of 4
Step 5
Secure the Swing Gate by lowering the Swing Gate
Latch. Wrap the safety chain around both guardrail
posts and insert the end of the safety chain into the
key hole slot.
Swing Gate Latch
(Shown Open)
Wrap safety chain
around both
guardrails
Adjustable Swing Gate
Installation and Use
Part #70910
IMPORTANT!
Guardrail Outriggers MUST be used at both ends of any
interruption in continuous guardrail sections, or at both ends
of a continuous guardrail section.
