x Page 10 xPre-Delivery Instructions Page 10
BENGAL (MM) 230 VOLT PERMANENTLY CONNECTED MODEL
WARNING! The exact physical location of the terminals on the GFCI
breaker will vary between manufacturers. Connecting the hot wire to
the neutral terminal will cause irreversible damage to the control box.
L1 #10 AWG BLUE
54321
L2 #10 AWG RED
N #10 AWG WHITE
L2 #12 AWG RED
L2
L1
L1 #12 AWG BLUE
GRD
GROUND #10 AWG GREEN
GRD
#8 AWG WHITE, NEUTRAL
#10 AWG GREEN, GROUND
#8 AWG BLUE, L1
#8 AWG RED, L2
N
20A
50A
230V, 50 Amp,
2–POLE,
CIRCUIT BREAKER
(NON GFCI)
30A
LESS THAN 100 FT.
MAIN SERVICE
ELECTRICAL
PA NE L
CONTROL BOX
TB1
HEATER
GROUND
*PROVIDED WITH SPA. NOTE: ALL WIRING SHOULD BE COPPER.
CASPIAN 230 VOLT PERMANENTLY CONNECTED MODEL
NOTE: The wire connections to GFCI breakers are for reference only. Always ensure
the white neutral wire is connected to the load neutral of the 30 amp breaker.
L1 #10 AWG BLUE
54321
L2 #10 AWG RED
N #12 AWG WHITE
L2 #12 AWG RED
L2
L1
L1 #12 AWG BLUE
GRD
GROUND #10 AWG GREEN
GRD
#8 AWG WHITE, NEUTRAL
#10 AWG GREEN, GROUND
#8 AWG BLUE, L1
#8 AWG RED, L2
N
20A
50A
230V, 50 Amp,
2–POLE,
CIRCUIT BREAKER
(NON GFCI)
30A
LESS THAN 100 FT.
MAIN SERVICE
ELECTRICAL
PA NE L
CONTROL BOX
TB1
HEATER
GROUND
*PROVIDED WITH SPA. NOTE: ALL WIRING SHOULD BE COPPER.
NOTE: The wire connections to GFCI breakers are for reference only. Always ensure the white
neutral wire is connected to the load neutral of the 20 amp breaker.
WARNING! The exact physical location of the terminals on the GFCI
breaker will vary between manufacturers. Connecting the hot wire to the
neutral terminal will cause irreversible damage to the control box.
To Next Page
