Instruction Guide Tiger TP-TG En 201812 v1.1
Geared Trolleys
Product
Code
Capacity
(tonne)
D - Track width #
Dimensions (mm)
Min.
curve
ratio (m)
Net
Weight
(kg)
Range 1
(mm)
Range 2
(mm)
A
B
C
E
F
G
H
J
K
Single Bar
Trolleys
TGS-0050
0.5
62-128
62-203
195
165
106
98
20
64
10
24
30
0.8
9.0
TGS-0100
1.0
62-128
62-203
213
170
113
106
20
71
10
27
34
1.0
11.0
TGS-0200
2.0
88-154
88-230
236
182
136
132
25
80
13
38
46
1.3
16.5
TGS-0300
3.0
88-153
88-230
270
184
146
150
25
97
13
42
53
1.5
23.5
TGS-0500
5.0
106-194
106-305
323
210
169
174
30
117
16
46
59
1.5
34.5
Twin Bar
Trolleys
TGT-0300
3.0
88-153
88-230
320
181
142
82
16
110
1.5
23.5
TGT-0500
5.0
106-194
106-305
352
202
166
91
24
131
1.5
34.5
TGT-1000
10.0
150-320
N/A
460
335
255
248
42ǂ
182
23
74
100
2.7
150.0
TGT-2000
20.0
150-320
N/A
930
335
255
270
42ǂ
182
35
85
95
6.0
356.0
TGT-2500
25.0
150-320
N/A
930
335
255
278
42ǂ
182
38
100
115
6.0
363.0
TGT-3000
30.0
150-320
N/A
990
348
267
288
42ǂ
182
38
100
115
6.0
368.0
Standard geared trolley hand chain length – 2.5m. We can change the length to suit your requirements.
Notes:
H is the thickness of the anchor point, J is the width of the anchor point opening and K is the height of the anchor
point opening.
ǂ A beam flange thickness up to 50mm can be accommodated if required – please ask for more information.
# Please contact us for track widths outside of these ranges.
Single Bar
Twin Bar 3.0t – 10.0t
Twin Bar Trolley 20.0t – 30.0t
Due to our policy of continual product development, dimensions, weights and specifications may change without
prior notice.
