8. Maintenance
Every Ever
y Every
25 50 100
System/components Procedure
Before
hours hours hours
Note
use
after
after
after
fuel leaks, fuel spillage wipe out ✔
fuel tank, air filter, fuel filter inspect/clean ✔✔ r
eplace, if necessary
see adjusting replace carburetor
idle adjusting screw ✔
idling speed if necessary
clean and r
eadjust GAP: 0.6 ~ 0.7 mm
spark plug ✔
plug gap
replace, if necessar
y
intake air cooling vent clean ✔
throttle trigger, stop switch
check operation ✔
clean
take it to a service dealer
cutting parts ✔
if somethings wrong
gear case grease ✔
scr
ews/nuts/bolts tighten/replace ✔✔not adjusting scr
ews
plate receive make sure to attach ✔
ENGINETRIMMER
WARNING
• Make sure that the engine has stopped and is cool
before perf
orming any service to the machine. Con-
tact with moving cutting head or hot muffler may
result in a personal injury.
BLADE
• Clean any resin and plant reside from the blade be-
fore and after using the machine.
• Check the cutting edges and reform with a flat file.
WARNING
•
Make sure that the blade bolts are well tightened.
• The blade assembly is designed to automatically
compensate for any play between the blades.
Point :
1. Keep the end corner sharp.
2. Round the root of the edge.
3. Do not use water when using a grinder.
IMPORTANT
When mounting the blade, make sur
e to fasten the
spacer, washer and bolt, then fasten the nut.
■ SHARPENING
Always keep the file or sharpener at an angle of 45° to
the blade, and:
• Always grind in the dir
ection of the cutting edge;
• Note: files cut only in one direction; lift the file from
the blade when returning to start a new pass;
• Remove all burr from the edge of the blade with a slip
stone;
• Remove as little material as possible;
• Before refitting the sharpened blades, remove filings
and then apply grease.
Do not try to sharpen a damaged blade: change it or
take it to a Service dealer.
GB 11
