Timbertech DeckLites - TimberTech DeckLites LED Components and Safety; DeckLites LED Components Overview; Required Tools for Installation; Important Safety Precautions

83
For information about DeckLites
®
LED visit www.timbertech.com/DeckLites.
Visit www.timbertech.com/installation to view TimberTech installation videos.
DeckLites Components
1
Important Safety Precautions
INSTRUCTIONS PERTAINING TO A RISK OF FIRE OR INJURY TO PERSONS
IMPORTANT SAFETY INSTRUCTIONS
WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS:
Turn off/unplug before servicing fixtures. Contact only switch/plug when
turning on.
Keep lamp away from materials that may burn.
Do not operate the luminaire fitting with a missing or damaged cover.
SAVE THESE INSTRUCTIONS
Stair Riser Light
Silicone Filled
Wire Nuts
(20/bag)
100W Transformer
16/2 AWG Wire
5 x 5 Post Lamp Module
RadianceRail
4 x 4 Post Lamp Module
Ornamental Rail, RadianceRail Express
Accent Light
In addition to a basic tool set, you will need the following
for installation of DeckLites components.
Drill Bits:
3/8”
7/64”
1/4”
3/16”
2.5mm
Allen Wrench
Spade Bits:
5/8”
3/4”
1”
1-1/2”
Tools Required
Cable Guide
& Screw
(12/bag)
®
In-Deck Light Under-Rail Light
PDF !"# "pdfFactory Pro" $#%&'( www.fineprint.cn
Dimmer*
*For installation instructions for the dimmer, visit http://www.timbertech.com/installation/installation-resources
