5070 Ductor Tester and Micro-Ohmmeter Calibrator v1.1
5070 Ductor Tester and Micro-Ohmmeter Calibrator Page 3 of 8
1.3 Specifications
Resistance Range Resistance values Accuracy Max current
200 μΩ 50, 100, 150, 200 μΩ 0.8 % 200 A
2 mΩ 0.5, 1, 1.5, 2 mΩ 0.5 % 100 A
20 mΩ 5, 10, 15, 20 mΩ 0.2 % 30 A
200 mΩ 50, 100, 150, 200 mΩ 0.1 % 10 A
2 Ω 0.5, 1, 1.5, 2 Ω 0.1 % 3 A
The currents shown above are the continuous rated for both AC and DC.
Higher currents (as generated by pulse driven instruments) can be used with an ON to OFF
time ratio of 1:10 or less. The allowed peak currents are 10 times those specified above, with
an upper limit of 1000 A and a maximum applied time of 4 seconds. At least 1 minute should be
allowed between applications for cooling.
NOTE:
It is important to ensure there are adequate low resistance connections to the 5070 current terminals.
1.3.1 General Specifications
Dimensions ........................... W 540 x H 210 x D 410 mm
Weight ................................... 11 kg
1.3.2 Ordering Information
5070 ....................................... Ductor Tester and Micro-Ohmmeter Calibrator
C146 ...................................... Traceable calibration certificate (Factory)
C107 ...................................... Accredited calibration certificate (ISO 17025)
