1. General:
This time switch is a compact and easy to use
digital 7 day timer module. It can control outputs
of up to 16A which makes it suitable for domestic
immersion heaters.
The NTM02 also has volt free contacts,
making it suitable for a wider range of
switching applications.
Programming can be 7 day, 5 + 2, or 24 hour.
NTM02 – 7 Day Digital
Timer Module
Power LED Output LED
Advance
button
Boost
button
Programme
button
Illuminated
screen
Reset
button
Time
button
