CHAPTER I
T
HIS iMANUAL IS written for operators
and service personnel.
It
provides infor-
mation for setting q3, playing, testing,
and maintaining your Hoop It Up” game.
Hoop It Up is a two-player basketball
rcdemp-
cion
game
featuring
real basketball controls that
shoot air-activated balls into miniature hoops and
nets.
Chapter 1 of this manual contains
set-up
and
game play information.
9
Chapter
2
contains a de-
scription of the test functions and option settings.
The test modes are important in rhc Hoop It Up
game. Using the tests, you can troubleshoot the large
light-emitting diode (LED) score
diplays,
the game
printed-circuit
board, and the controls. You should
regularly do these tests to keep your game in
peak condition and
at
top
earnings. + Chapter
3
contains a troubleshooting table, plus
mainre-
nance
and repair procedures for rhe game compo-
nents. If you have problems with your game,
use
this
chapter to troubleshoot and repair it.
+
Chapter
4
contains the illustrations and Score Board PCB paru
list.
4
Chapter 5 contains
the
game wiring diagram
and the Score Board PCB schematic diagram.
Copies of the game PCB schematic are available free
of charge by contacting our Customer Service
Dept.: see the inside front cover of this
manual for the address and telephone
To Next Page
