Instruction manual
NX
- 7 -
Seat clamp
Figure 3
3) Saddle height adjustment
Setting the saddle height is done in a traditional manner. Be careful that the final position of the
seatpost is between the two markings, ‘max. extension’ and ‘max. insertion’. (fig 4).
Insertion
MAX
Adjustment range
Extension
MAX
Figure 4
