7
7. Extra Low Voltage Wiring:
Single Zone Control Unit (Rear)
Over-D oor Light
Reset Unit
Pull Cord Unit
Out
Out In
NE L
Out In
WARNING
Do not
connect to
mains supply!
Mains Rating
Information
Connector
for incoming
mains supply
Control
Board
2 Wire Extra
Low Voltage
Fixing
Holes
Fixing
Holes
Fixing
Holes
Components must be wired in the order shown above
