CONNECTOR INSTALLATION
Carefully inspect the completed wiring before connecting the TIMEMASTER.
WIRE
COLOR
PIN# USED FOR
purple 1 24 volt pulse to mechanical coin counter
orange/black 2 coin pulse from coin acceptor
green/black 3 last minute horn (24 volts DC ground)
red/black 4 last minute horn (24 volts DC hot)
light green 5 safety ground
blue/black 6 timed output
yellow 7 jumpered (DO NOT USE)
yellow 8 jumpered(DO NOT USE)
green 9
TIMEMASTER power (24 volts AC
neutral)
orange 10 TIMEMASTER power (24 volts AC hot)
Pin #1
COIN COUNTER PULSE (output) See Figure 3.
A 24 volt AC pulse is output on pin 1 in response to an input from pin 2 each time a coin is deposited. Normally, this pin is connected to one terminal of a mechanical coin
counter in the equipment room for accounting purposes.
Pin #2
COINT ACCEPTOR PULSE (input) See Figure 3.
