9
OPERATION
DIP Switches
There is a 3 way dip switch responsible for 3 functions:
1: Pump Exercise Function
2: Pump Delay Function
3: RF Test Enable
In normal use, these DIP switches can be ignored and should be down in the OFF position.
DIP Switch 1
To enable the pump delay, put switch 1 to the ON position.
DIP Switch 2
To enable pump exercise function, put SW2 to the ON position.
DIP Switch 3
The boiler RF test switch is used to test communications with the RF-Switch receiver.
