1. INTRODUCTION
1.1 TILLER IDENTIFICATION
Each tiller has a plate for unique identification. Any request for assistance or information
regarding the machine must be directed to the Manufacturer or Dealer always referring to the
model and serial number as shown on the Serial Number Plate affixed to the machine.
1.2. INTENDED USE
The Rotary Tiller are designed to be used uniquely for horticultural, agricultural applications, to
till soil for seedbed and planting preparation. They are designed to be mounted on tractors
equipped with hydraulic lift and universal three-point hitch that can support the implement
weight and driven by the power of the tractor through the PTO drive shaft.
DANGER
Any use of the machine other than the intended use is to be considered as unauthorized and
dangerous. The manufacturer assumes no liability for damage resulting from non-intended use.
1.3 MAIN PARTS DESCRIPTION
1. Frame Assembly
2. 3-Point Linkage
3. Gear Box
4. Side Gear Drive
5. Plank Board
6. Rotor Assembly
7. Blade
8. RT Parking Stand
9. Depth Skid
