Titan PGD2875 - PGD2875 Parts List

Parts List and Exploded View of PGD2875 Driver
No.
Part Name
Qty
No.
Part Name
Qty
1
140FA Gasoline Engine
1
26
Inner Hexagon Cylindrical-Head Screw
M6×20
4
2
Driven Disk
1
27
Cylinder Gaskets
1
3
Inner Hexagon Cylindrical-Head
Screw M5×12
3
28
Impact Connecting Rod
1
4
Elastic Washer 5
3
29
Impact Piston
1
5
Bearing Pressing Plate
1
30
Impact Piston Pin
1
6
Deep Groove Ball Bearings 6202-2RS
3
31
O-Ring Impact Piston
1
7
Small Bevel Gear 7-2
1
32
Impact Cylinder
1
8
Reduction Gearbox
1
33
Middle Paper Pad
1
9
Grease Cover
1
34
Hammer Case
1
10
O-Ring Grease Coverφ1.5×50
1
35
Elastic Washer 8
8
11
Inner Hexagon Cylindrical-Head Screw
M6×16
1
36
Inner Hexagon Cylindrical-Head Screw
M8×20
4
12
Elastic Washer 6
5
37
Front Paper Pad
1
13
Retainer
1
38
Hammer O-Ring
1
14
Needle Roller Bearings HK152316
1
39
Hammer
1
15
Crankshaft
1
40
Crush Pad
2
16
A-Type Common Flat Key 5×5×10
1
41
Waved Gasket φ39×46×0.5
6
17
Deep Groove Ball Bearings 6003-2RS
2
42
Shock O-Ring
2
18
6003 Bearing Pressing Plate
1
43
Shock
1
19
Cross Pan Head Screw M5×14
4
44
Support Plate
1
20
Large Bevel Gear 28-2
1
45
Hexagon Flange Nut M18×1.5
2
21
Shaft Retainer 16
1
46
Impact Socket
1
22
Rear Paper Pad
1
47
Piling Socket
1
23
Round Pin 4×10
2
48
Inner Hexagon Cylindrical-Head
Screw M8×40
4
24
Reduction Gearbox Cover
1
49
Inner Pile Head 77
1
25
Inner Hexagon Cylindrical-Head Screw
M5×20
4
50
Piling Socket Sleeve
1
