-10-
It is normal for the canister hood and tool storage cover to come off when opened further
than needed. Line up the hinge slots, insert the hinges into the slots, and close the hood
and tool storage cover to reinstall.
Line up the hose latch tab and notch in canister hood and insert hose into canister until it
snaps into place.
To remove: Do not open hood before removing hose. With hood closed, depress hose latch
tab. Pull upward on hose.
Never open canister hood with the tool storage cover open. This will help to prevent
damage from occurring to the canister hood and/or tool storage cover.
CAUTION
HOOD AND TOOL STORAGE COVER
HOSE TO CANISTER
Notch
Hose
Latch
Tab
