Your product
10
13
5
4
3
2
1
6
7
9
8
11a
12
11
16
15
14
18
18
17
1. Feeding funnel
2. Transportation handle
3. Power supply
4. Blade compartment
a. Guard*
b. Cutting blade*
c. Cutting plate*
5. Cutting plate adjustment knob
6. Discharge chute
7. Base plate
a. Screw* (x 4)
b. Washer* (x 4)
8. Frame
9. Foot assembly (x 2)
a. Foot
b. Base*
c. Bolt*
d. Nut*
10. Wheel assembly (x 2)
a. Wheel*
b. Slot*
c. Bolt*
d. Bushing*
e. Nut*
f. Cover*
g. Latch*
h. Washer* (x 6)
11. Collection box
a. Interlock switch
b. Recessed grip*
12. Air vents
13. Forward/reverse switch
14. OFF switch “O”
15. ON switch “I”
16. Reset button
17. Plunger
18. Assembly wrench (x 2)
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective section in the instruction manual.
TTB683SHR
by TITAN TTB683SHR by TITANYour product Your product
14 15
Technical specifications
Rated voltage, frequency
Rated power input
Degree of protection
No load speed
Max. cutting diameter
Collection box capacity
Weight
Sound pressure level L
pA
Uncertainty K
pA
Measured sound power level L
WA
Uncertainty K
WA
Guaranteed sound power level L
WA
(acc. to 2000/14/EC amended by
2005/88/EC)
>
>
>
>
>
>
>
>
>
>
>
>
230-240 V~50 Hz
S1: 2000 W, S6: (40%) 2500 W
IP24
2850 min
-1
Ø 40 mm
60 l
28 kg
82.7 dB(A)
3 dB(A)
90.7 dB(A)
2.41 dB(A)
93 dB(A)
:
:
:
:
:
:
:
:
:
:
:
:
Noise level
