Titan TTB903TCH - Page 25

Fig. 17
Fig. 18
25
Product functions
TTB903TCH by TITAN
In more detail…
Making a straight cut
Adjust the parallel cutting guide (12) to the desired width. Use the locking knob
to loosen or adjust the guide. Position the tile firmly against the parallel cutting
guide (12) and pass through the cutting disc in a smooth action. Hold the edges
of the tile and press down firmly to prevent the tile lifting during the cut.
7
12
EN
