In more detail . . .
4. Remove any dirt accumulated inside the guide bar (2) slot using the putty knife (not
provided) (Fig. 42).
42
5. Check the guide bar “rail” for wear: Hold a ruler (straight edge) against the side of
the guide bar (2) and “cutter side plates”. If there is a gap between the ruler and
guide bar (2) the guide bar “rail” is normal. If there is no gap (ruler ush against the
side of the guide bar (2) the guide bar “rail” is worn and needs to be replaced with
a new one of the same type (Fig. 43).
43
6. Check the saw chain (3) for possible wear and damages. Replace it with a new
one if required. Experienced user can sharpen a dull saw chain (see section “Saw
chain sharpening” below).
7. Ret the saw chain (3) and the guide bar (2) as described under section “Assembly”.
Saw chain sharpening
NOTE: Never saw with a blunt chain. The saw chain is blunt if you have to
push the product into the tree and the chips are very small.
1. Have the saw chain (3) sharpened professionally at an authorised service centre or
sharpen the chain yourself by using the le (27).
WARNING! Only sharpen the saw chain yourself if you are trained and have
experience! Use proper tools to sharpen the saw chain!
Care and maintenance
