Transmitter
VHF Power Output: 8 watts minimum, 50 ohm
Modulation: 85% capability with 90% limiting provided.
Microphone: Dynamic mike containing transistorized pre-amp
or carbon (must provide at least 120 m Vrms into
500 ohm load).
Side tone: Adjustable up to 40 mw into 500 ohm
headphones.
Duty Cycle: 1 minute on, 4 minutes off (20%)
Receiver
Sensitivity: 1.5 uv (soft) will provide a 6 db minimum signal
plus noise to noise ratio (KHz, 30% mod).
Selectivity: Typical 6 db at
+1-7.5
KHz, 60 db at
+1-
17.5 KHz, 90 db at +25KHz
Spurious Responses: Down at least 70 db.
Squelch: Noise adaptive squelch with override.
AGC Characteristics: From 2 to 100.000 uV audio
output will not vary more than 1 db.
NAV Receiver
Crystal Controlled: 200 Channels
Frequency Range: 108.00 to 117.95 MHz
Sensitivity: 1.5 uv (soft) will provide a half flag indication.
Selectivity: Typical 6 db at
+1-
15 KHz 60 db at
+1-
35 KHz, 80db at + 50 KHz
Spurious Responses: Down at least 70 db.
