5
C. SPECIFICATIONS
MX385 TRANSCEIVER
Mounting: Panel mounted, no shock mounting
required.
Size: 6.312 x 2.50 x 11.1 inches w/
connectors but excluding knobs.
Weight: 6.0 lbs excluding external connector
and harness.
Power Requirements: 27.5 Vdc at 0.7 Amp
Max COMM Total w/
Transmit (Tone) 3.0 Amp
COMM TRANSCEIVER
Crystal Controlled: 760 Channel
Frequency Range: 118.00 to 135.975 MHz
Frequency Stability: +/- .003%. –20 to 50 C
TRANSMITTER
VHF Power Output: 8 watts minimum, 50 ohm
Modulation: 85% capability with 90% limiting
provided.
Microphone: Dynamic mike containing
transistorized pre-amp or carbon
(must provide at least 120 mV rms
into 500 ohm load)
Sidetone: Adjustable up to 40 mw into 500 ohm
headphones.
Duty Cycle: 1 minute on, 4 minutes off (20%)
