6
RECEIVER
Sensitivity: 1.5 uv (soft) will provide a 6 db
minimum signal plus noise ratio
(KHz, 30% mod).
Selectivity: Typical 6 db at +/- 7.5 KHz, 65 db at
+/- 17.5 KHz, 90 db at +/- 25 KHz.
Spurious Responses: Down at least 70 db
Ident Filter: 15 db minimum
AGC Characteristics: From 2 to 100.000 uV audio output
will not vary more than 1 db.
NAV Receiver Accuracy: Two sigma limit, +/- 1 degree
NAV Output: With LOC adjusted for 0.35 Vrms
VOR = 0.5 Vrms (typical) into 20K
ohms or greater load impedance.
DME Channeling: 2 x 5
G/S Channeling: 2 x 5
AUDIO
Auxiliary Audio Inputs: Eight 500 ohms with 30 db isolation
between any two.
Frequency Response: Within 6 db from 350 Hz to 2500
Hz
Headphone Output: 40 mw into 500 ohm
Speaker Output: 4.5 Vrms into auxiliary input
produces 5 watts audio output.
