Assembly
Step 13
Note: This step is only used if you do not have the Leg Press attachment. Use
the Cable Adapter (#113) in place of the pulley.
Note: Stretch all cables out completely and make sure all twisting is removed
before installing.
Install Leg Press Cable Substitute (#47) as detailed in Figure 13. Follow dotted
lines to identify exact location of pulleys. See Page 29 "Cable View" for more
detail.
You will need the following for installation:
one Cable Adapter (#113) two Longer Pulley Spacer (#55)
one Cable (#47) one M10*80 BHCS (#95)
two Φ11*Φ20*2 Flat Washer (#102) one M10 Nylon Locknut (#104)
Note: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled.
Step 14
Note: Stretch all cables out completely and make sure all twisting is removed
before installing. Install Pec Dec Cable (#49) as detailed in Figure 14. Follow
dotted lines to identify exact location of pulleys. See Page 29 "Cable View" for
more detail.
You will need the following for installation:
one Cable (#49) three Pulley (#44)
one Pulley Bracket Block (#22) three M10*45 BHCS (#91)
six Φ11*Φ20*2 Flat Washer (#102) three M10 Nylon Locknut (#104)
two M4*20 Phillips Screw (#85)
Note: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled.
