TKO 6610 - Step 15: Connect Lat Bars and Straps; Step 16: Install Weight Shrouds

To Next Page

To Previous Page

─ 26 ─

Assembly

Step 15

Connect Long Lat Bar (#70) to the Chest Press Cable (#45) using two Gear

Hooks (#33) and Short Chain (#35).

Connect Ab Strap (#40) or Lat Strap (#34) to Mid Pulley Cable (#46) using one

Gear Hook (#33).

Connect Short Lat Bar (#71) to Mid Pulley Cable (#46) using two Gear Hooks

(#33) and Long Chain (#32).

Note: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled.

Step 16

Install Weight Shrouds (#20) to each side of the Main Top Beam (#4) using:

two Φ11*Φ20*2 Flat Washer (#102) two Φ10 Spring Washer (#103)

M10*25 BHCS (#97) two M8*15 BHCS (#118)

Secure the bottom portion of the Weight Shrouds (#20) to the Rear Frame (#1)

using:

two M8*15 BHCS (#118) two Φ9*Φ22*2 Flat Washer (#119)

Note: Wrench Tighten bolts and Nylon Lock nuts.
