HDMI HDMI output port
RS-232 serial port for printing information
XLR L XLR output port for balance audio L channel
XLR R XLR output port for balance audio R channel
GND Grounding terminal
Power Socket AC 90~250V 50-60Hz input
Note: This RS-232 interface is a 9-pins female sub-D connector that is only used for factory software
upgrade and configuration. You may not connect any cable to the RS-232 connector, as that could
cause damage to the device.
3.3 Description of menu
Status
to show the status of signal inputs for ASI, and TUNER
DVB-S2/QPSK
This menu only is shown on DCH-3100P-S2 model
LNB Frequency: Input LNB frequency
Satellite Frequency: Input downstream frequency of satellite
Symbol Rate: Input symbol rate of satellite
LNB Voltage: select the correct LNB voltage output of the F-connector: Off, 13
V, 18 V. <13V for Vertical/Left hand polarization, 18V for Horizontal/Right hand,
OFF for LNB Power off.>
LNB 22KHz: activate the LNB 22 kHz control signal to the LNB: On or Off.
<22KHz control signal switches the LNB to receive high band if any>
DISQEC: Can select OFF/Port A/Port B/Port C/Port D
COFDM
This menu only is shown on DCH-3100P-T model
Frequency: enter the proper frequency of the COFDM signal in MHz.
Bandwidth: set the bandwidth from 6M/7M/8M
QAM
This menu only is shown on DCH-3100P-C model
Constellation: enter the modulation mode of the QAM signal.
Frequency: enter the frequency of the QAM signal in MHz.
Symbol Rate: edit the symbol rate to the proper value in KBaud.
Input
RSSI
to show the quality of receiving DVB-S2/S signal.
