D. Instrument Panel
The GPU’s instrument panel is located at the rear extreme of the unit. It provides the operator with controls and
displays for generator and engine functioning.
INSTRUMENT PANEL
FIGURE 10
1…Blue Button
2…Red Button
3…Yellow Button
4…Green Button
5…Dial with Pushbutton
6…LCD Screen
7…Emergency Stop
4
1
2
3
5
7
6
