Creation:03.09 — 2009 1-1-6

Description

1. Drive plate assembly 9. Endbell

2. Coupling hub 10. Exciter field

3. Screen cover 11. Bearing

4. Adapter 12. Exciter armature

5. Fan assembly 13. Rotating rectifier assembly

6. Aluminum baffle 14. Ring Resistor

7. Generator frame and stator assembly 15. Exciter cover

8. Generator rotor assembly 16. Drip proof shield

TYPICAL GENERATOR BREAKDOWN

FIGURE 5
