Creation:03.09 — 2009 1-1-7

Description

C. Control Box

1. Electrical Box Assembly:

The electrical box assembly is located at the extreme rear of the unit and houses the

instrument panel and the relay panel. It also provides a place for the engine’s electronic

control module (ECM) to mount to. This is located on the outside of the electrical box

back wall and accessed from inside the GPU.

1. Electrical Box

2. Instrument Panel Assembly

3. Relay Panel Assembly

ELECTRICAL BOX ASSEMBLY

FIGURE 6
