1-3-1
GPU - 406
GPU
-
409
Specifica
tions and Ca
pabilities
1.
GPU-400 SE
RIES
MODEL
KVA
P.F.
KW
RATED
AMPS
LENGT
H
TOWB
AR UP
WIDT
H
HEIGHT
GPU-406
60
0.8
48
170
112"
2845 mm
68"
1728 mm
W
ith beacon
64"
1630 mm
W
/O beacon
59”
1502 mm
GPU-409
90
0.8
72
260
112"
2845 mm
68"
1728 mm
W
ith beacon
64"
1630 mm
W
/O beacon
59”
1502 mm
34
