TLV COSR-3 User Manual

172-65174MA-11 (COSR Pressure Reducing Valve) 16 Feb 2022
8
No.
Name
A*
B*
C*
D*
E*
No.
Name
A*
B*
C*
D*
E*
1
Main Body
16
Spring Housing
2
Cover Plug**
17
Adjustment Screw
3
Main Valve Seat

18
Spanner Cap
4
Main Valve

19
Plug – Sensing Line Port
5
Main Valve Holder

20
Lower Pilot Body Gasket



6
Piston

21
Cover Plug Gasket


7
Cylinder

22
Main Valve Seat Gasket


8
Pilot Body
23
Pilot Screen Holder
Gasket


9
Pilot Valve

24
Pilot Valve Seat Gasket


10
Pilot Valve Seat

25
Upper Pilot Body Gasket


11
Diaphragm
26
Cylinder Gasket


12
Pilot Screen

27
Piston Ring


13
Pilot Screen Holder
28
Tension Ring


14
Diaphragm Support
29
Main Valve Spring

15
Coil Spring
30
Pilot Valve Spring

*Replacement parts are available only in the following kits:
A = Maintenance Kit
B = Repair Kit for Main Valve
C = Repair Kit for Piston
D = Repair Kit for Piston Rings
E = Repair Kit for Pilot Valve
**Size 15 mm for COSR-3 is not available
