TMC 30E - Page 117

Injection Molding Machine Chapter 5
V3.0
5-12
Content of Alarm Cause of Alarm Release of Alarm
36. Robot connection
error
Please check robot
input I/O222
S/A: T/C 326 time counting
completed I/O 222 OFF
1. Open safety gate
2. Adjust T/C 326 set value
3. Check robot
37. Auto mold adjustment
not finish
Please check die hei
g
ht
adjustment
M: function not selected
before operation or set
value improperly
1. Open safety gate
2. Adjust die height
adjustment set value
3. Check mold actual
condition
38. Auto mold adjustment
finished
M: Auto mold adjustment
completed
1. Open safety gate
39. Emergency circuit is
opened
Check emergency
circuit
M/S/A: front or rear
emergency stop
button is pressed or
side gate on clamp
side or rear
operation gate is
opened.
1. Open safety gate
2. Release emergency stop
button
3. Close side door， e.g.， rear
operation gate.
41. Motor Ì not confirm
IO 231， IO 232
M/S/A: after pump motor is
“ON” I/O 231， I/O
232 is not ON
1. Open safety gate
2. Check motor circuit
71. Temperature over
danger point
M/S/A: Actual temperature
Exceeding
dangerous
temperature
1. Open safety gate
4. Check temperature set value
3. Check temperature control
circuit
