Injection Molding Machine Chapter 4
V3.0
4-12
completely release mold close hydraulic pressure.
Ｈ RE-CLOSE COUNT：If mold is not closed to the end point before MOLD PROTECTION T.
expired，then mold open→ ejector advance/retract→ mold close again，if the mold can
not be locked up within the counters of clamp re-close，alarm is activated.
Ｉ EJECT ON FLY PT.：Option feature. When mold is opened to this position，ejector
sequences start.
Ｊ LUBRICATION T.：It’s the lubrication time for each lubrication process. Please refer to
Table 4-1.
Ｋ LUB. COUNT：Total mold close cycle that to initiate lubrication process.
Ｌ CLOSE < > SECTION：Mold close sections.
Ｍ OPEN < > SECTION：Mold open sections.
Ｎ Reserved function.
Time The 1
st
week The 2
nd
week The 2
nd
month The 2
nd
year
Model LUB.
TIME
LUB.
COUNT
LUB.
TIME
LUB.
COUNT
LUB.
TIME
LUB.
COUNT
LUB.
TIME
LUB.
COUNT
60E-150E 20.0 15 20.0 30 20.0 90 20.0 150
200E-350E 25.0 10 25.0 20 25.0 60 25.0 90
500E-1000E 30.0 5 35.0 10 35.0 30 35.0 50
Table 4-1
